Residential Battery Storage · 16 kWh · EU Warranty

HLY-BESS-Residential-16kWh

Stackable floor-standing LFP home battery. 16 kWh per unit. Parallel-expandable to 240 kWh.

HLY-BESS-Residential-16kWh · 51.2 V · 314 Ah · IP21

6,000 cycles. 314 Ah. CAN/RS485. Floor-standing stackable. Engineered in Shandong, China.

At a glance

The HLY-BESS-Residential-16kWh is a stackable floor-standing LFP home battery — 16 kWh, 314 Ah, 200 A continuous. 6,000 cycles at 80% DoD and 25°C per IEC 62619. Up to 15 units in parallel for 240 kWh aggregate. Manufactured in Dezhou, Shandong; EU projects serviced from Romania.

6,000

Cycles

80% DoD · 25°C · per IEC 62619

314 Ah

Rated Capacity

16 kWh · 200 A continuous

5+5 yr

Warranty

Insurance-backed option

240 kWh

Max Aggregate

15 units in parallel

Why installers specify this platform

Four reasons the wheeled LFP platform wins residential installs.

No wall penetrations · No structural calcs

True Zero-Fixings Install

Wheeled chassis means no wall drilling, no structural load calculation, no landlord permission. Roll it in, connect it, commission it.

CAN / RS485 · 30+ inverter brands verified

Inverter Compatibility by Design

CAN and RS485 are the protocols every residential hybrid inverter speaks. There’s no proprietary lock-in. Verified compatibility lists and firmware versions for 30+ brands (Deye, Goodwe, Sofar HYD, SMA, Victron, SolarEdge) are available on request.

Max 15 units · Up to 153.6 kWh

Modular from Day One

A homeowner who starts with one 16 kWh unit can add more later without touching the original install.

LFP · No thermal runaway cascade risk

Safe Chemistry for Living Spaces

LiFePO₄ thermal propagation is substantially slower than NMC, and the activation energy threshold is higher. IEC 62619 testing validates this at module level. No cobalt, no NMC. Insurance underwriters read those test reports.

Technical specifications

HLY-BESS-Residential-16kWh — stackable floor-standing, 16 kWh.

HLY-DS-Residential-16kWh · v1.0 · May 2026

Parameter

51.2 V · 16 kWh · IP21 · floor-standing · stackable

HLY-BESS-Residential-16kWh

Battery System
Rated Energy	16.0 kWh
Rated Capacity	314 Ah
Max Power Output	16.0 kW
Max Charge / Discharge Current	200 A
Nominal Voltage	51.2 V
Operating Voltage Range	44.8 V – 57.6 V
Cell Chemistry	LiFePO₄ — Cobalt-Free · Tier-1 LFP cells from publicly listed manufacturers, multi-supplier homologated · EU Reg 2023/1542
Cycle Life	≥6,000 cycles at 80% DoD · 25°C · EOL per IEC 62619
Warranty	5 years standard + 5 years optional extension
Battery Management System (BMS)
Communication	CAN / RS485
Max Parallel Units	15 units · 240 kWh max aggregate
Thermal Management & Environment
Cooling Method	Natural convection — no active cooling, no fans in battery
Charge Temperature	0°C to +55°C
Discharge Temperature	−20°C to +55°C
Enclosure & Physical
Protection Rating	IP21 — indoor or outdoor-sheltered (carport, shed, garage)
Mounting Method	Floor-standing · stackable · no civil work required
Dimensions W×D×H	940×270×500 mm
Weight (approx.)	~125 kg
Certifications & Compliance
Certifications	CE · IEC 62619 · UL 1642 · UN 38.3 · MSDS
EU Battery Regulation	LFP cobalt-free · battery passport in preparation
Service & Delivery
Service Network	9-region · EU service hub in Romania · spare parts stocked in-region
Lead Time	35 days ex-works Dezhou, Shandong

All values subject to confirmation at contract phase.

Three use cases

Solar self-consumption, backup, and ToU arbitrage.

Use Case 1 — Solar self-consumption

PV + Battery + Grid

Charges from solar during the day, discharges at night. A 16 kWh battery covers evening household load above 80% on a typical 6 kWp system in Central Europe.

HLY-BESS-Residential-16kWh

Use Case 2 — Backup power

Grid-tied backup on loss

Inverter switches to islanded mode within milliseconds on grid loss. A 16 kWh unit runs a refrigerator, lighting, router, and EV trickle charge for 8–14 hours.

Requires: hybrid inverter with backup / off-grid capability SKU: HLY-BESS-Residential-16kWh

Use Case 3 — ToU arbitrage

Charge cheap, discharge expensive

Charge overnight on low tariff, discharge at evening peak. Germany, France, Netherlands, and CEE markets with dynamic pricing make this economically viable.

Requires: inverter with ToU / time-based control mode SKU: HLY-BESS-Residential-16kWh

Parameter

Mode A · Integrated

Mode B · Central PCS

Mode C · Hybrid Inverter

PCS source

On-board, integrated in cabinet

External central PCS, separate skid

External hybrid inverter (PV + BESS)

Rated AC power

200 kW (215, 225 kW optional)

630 / 1,000 / 1,250 / 1,500 / 2,000 / 2,500 kW

30 / 50 / 60 / 100 / 125 kW

Typical scale

1–10 cabinets · 0.4–4.2 MWh

4–40 cabinets · 1.7–16.7 MWh

1–4 cabinets · 0.4–1.7 MWh

Typical sites

C&I behind-the-meter, single-cabinet retrofits

Utility BESS, large industrial, FCR/aFRR plants

Solar-plus-storage rooftops, microgrids

SKU

HLY-BESS-Commercial-Industrial-418kWh

HLY-BESS-Commercial-Industrial-418kWh-DC

HLY-BESS-Commercial-Industrial-418kWh-DC + HLY-Inverter-Hybrid

Spec table reflects Mode A. Battery, BMS, thermal, and EMS identical across all three modes — only PCS strategy differs. Sizing and pairing confirmed per project at engineering review.

System architecture

Built for a decade of indoor residential operation.

LFP · 51.2 V · Tier-1 multi-supplier · cobalt-free

Cell & Battery System

Tier-1 LFP cells from publicly listed manufacturers, multi-supplier homologated. No cobalt. IEC 62619-tested at cell level. LiFePO₄ thermal propagation is substantially slower than NMC. Specific supplier identification releases after NDA execution.

CAN · RS485 · 30+ inverter brands verified

Inverter Interface (Customer-Supplied)

CAN and RS485 — every residential hybrid inverter speaks these. No captive inverter. Compatible with Deye, Goodwe, Sofar HYD, SolarEdge, Victron, SMA, and 30+ others.

Multi-level BMS · active balancing · 7-inch display

Battery Management System (BMS)

Multi-level BMS at cell and system level. Active balancing. Real-time SOC on the 7-inch touchscreen. Remote monitoring via the inverter’s cloud platform — no separate gateway required.

IP21 indoor · natural convection · wheeled chassis

Thermal Management & Enclosure

Natural convection — no fans, no glycol. Discharge −20°C to +55°C, charge 0°C to +55°C. IP21: indoor and sheltered environments only.

Where this platform deploys

Six residential and small-commercial use cases.

Solar Self-Consumption

A 16 kWh battery covers evening household load on most days on a typical 6 kWp system — payback depends on your local feed-in versus import tariff gap.

Backup Power

A single 16 kWh unit powers a refrigerator, lighting, router, and EV trickle charge for 8–14 hours.

Time-of-Use Arbitrage

ToU tariffs in Germany, France, Netherlands, and CEE markets create overnight charge windows and evening discharge windows. Daily arbitrage on a 16 kWh system generates measurable payback over 10 years — exact numbers depend on your tariff spread.

Off-Grid Hybrid

Cabins and agricultural buildings need storage tolerating months of standby. LFP’s low self-discharge is the right chemistry. Storage −20°C to +55°C covers alpine or continental winter without active thermal management.

Small Commercial Behind-the-Meter

Small retail units and offices under 25 kW can parallel multiple units. Up to 15 units reaches 240 kWh — enough to buffer a 30–50 kW connection with afternoon demand spikes.

Installer Volume Pipeline

Ships on standard pallets, deploys without civil prep. Pre-commission in your own facility before delivery.

Regulatory readiness

Certified for European residential deployment.

IEC 62619

UL 1642

CE Declaration

UN 38.3

EU Reg 2023/1542

ISO 9001:2015

ISO 14001:2015

ISO 45001:2018

MSDS

RoHS

LiFePO₄ contains no cobalt, no nickel, no manganese — supply-chain due diligence under EU Reg 2023/1542 is substantially simpler than for NMC. CE marked. Battery passport in preparation for the 18 February 2027 deadline. We’re a 2022 manufacturer without a decade-long residential track record, and we say so. What we do have: IEC 62619 cell-level certification, EU-jurisdiction warranty, and spare parts stocked in Romania.

Manufacturer direct

Direct manufacturer warranty · 5+5yr coverage (insurance-backed option) · EU service hub in Romania · IEC test reports under NDA

Frequently asked questions

Questions from homeowners, installers, and solar integrators.

What is the difference between the 5 kWh and 10 kWh models?

Capacity, form factor, and weight. The 16 kWh is floor-standing and stackable (940×270×500 mm, ~125 kg), while the 5 kWh and 10 kWh are wall-mount. The 16 kWh carries a 314 Ah cell pack and 200 A continuous current. All three share the same 51.2 V LFP BMS, CAN/RS485, and warranty.

What cycle life does this battery carry, and under what conditions?

6,000 cycles at 80% DoD and 25°C ambient, per IEC 62619. Real-world ambient above 25°C cuts cycle count. Cycling at 70% DoD extends service life beyond the rated figure.

Does it work with my existing inverter?

CAN and RS485 — the protocols every residential hybrid inverter speaks. We supply a verified compatibility list covering 30+ brands, with firmware notes. Ask before ordering if you’ve got a specific model in mind.

Is this battery suitable for outdoor installation?

IP21 means protection against vertical dripping only — not weatherproof. Outdoor use requires a sheltered environment: carport, shed, or garage. The HLY-BESS-Commercial-Industrial line starts at IP54 for outdoor-rated systems.

Where is the residential battery serviced in Europe?

Henley Power services European projects from Romania — engineering and warranty support staffed locally. Spare parts stocked inside the EU. Nine service regions cover the EU, Eastern Europe, and Africa.

What does the warranty cover and is insurance available?

5 years system warranty, covering cells, BMS, and thermal management. A 5-year optional extension is available. Warranty insurance via licensed European insurer is available as a project option for DFI-financed and institutionally-backed tenders. Parent guarantee or escrow alternative on request.
